JL Audio C2 Car Tweeter

Overview
Specs
In the Box
Overview
The JL Audio C2 component tweeters deliver a clean and powerful sonic profile. Equipped with 0.75-inch silk dome diaphragms, the C2 component tweeters offer robust and extended response both on and off-axis. Included flush-mounting and surface-mounting fixtures cater to various installation preferences.
Specs GeneralWarranty1 yearSizes0.75″Continuous power handling (RMS)60 WSensitivity (SPL @ 1 W/1 m)91.0 dBFrequency response (+/- 3 dB)4 kHz-22 KHzNominal impedance8 ΩRecommended amplifier power (RMS)15-100 W/ChannelTweeter typeSilk DomeTweeter size0.75″ (19 mm)Networking & ConnectionsSpeaker connectionsSpade connectorsTweeter SpecificationsFlush mount fixture diameter1.87″ (48 mm)Surface mount fixture diameter1.69″ (43 mm)Flush mount mounting hole diameter1.625″ (41 mm)Flush mount mounting depth0.76″ (19 mm)Flush mount tweeter frontal protrusion0.29″ (7 mm)Surface mount tweeter frontal protrusion0.92″ (23 mm)In the Box
Two tweeters
Two crossovers
Two flush mount housings
Two surface mount housings
Two metal spring clips (for flush mounting)
Four flat head screws
Two 25 mm stud bolts
Two 10 mm stud bolts
Two M5 nuts
